Stainless Steel Screen Printing Mesh

类别:

REQUEST INQUERY

Features:
All Haocheng screen printing meshes have a high resistance to aggressive inks and pastes, despite their fine structures. Precisely defined cloth thicknesses, very high mesh accuracies and tight tolerances as well as precisely defined print layer thicknesses permit outstanding print results. In addition to a large standard programme for different application profiles, we also manufacture individual special solutions.

Application:
Widely used in the plate making of electronics, textiles, ceramics, glass and other industries and filtration of aviation, airspace and petrochemical industries.

Plain Weave Stainless Steel Screen Printing Mesh
Item Mesh count Thread Diameter Open Area Aperture
Mesh/inch um % um
SPMS-200-50 200 50 37.0 77
SPMS-230-35 230 35 46.7 75
SPMS-250-40 250 40 36.8 62
SPMS-250-30 250 30 49.7 72
SPMS-250-35 250 35 43.0 67
SPMS-270-35 270 35 39.4 59
SPMS-300-30 300 30 41.7 55
SPMS-325-30 325 30 38.0 48
SPMS-325-28 325 28 41.2 50
SPMS-325-23 325 23 49.8 55
SPMS-350-25 350 25 43.0 48
SPMS-400-23 400 23 40.7 41
SPMS-400-18 400 18 51.3 46
SPMS-500-18 500 18 41.7 33
